Factcheck: Mineral Independence and the Pebble mine

One of the arguments made in favor of development of the proposed Pebble mine is that it would create a domestic supply of copper, gold, and molybdenum and would contribute to resource independence for the United States.¹

Northern Dynasty Minerals (NDM) added the critical mineral rhenium to that list in August, saying, “As a significant deposit of Rhenium on US soil, development of the Pebble resource will materially advance America’s goal of achieving self-sufficiency in the critical minerals needed to support and sustain its economic growth, military security, manufacturing industries and transition to a lower carbon future.”²

The existence of these minerals on U.S. soil is just the first part of the equation, however. The argument ignores a critical aspect of the supply chain: how concentrate gets turned into a product ready for end users. That’s where the U.S. loses out on any resource independence advantage from the Pebble deposit.

Pebble developers have been clear that concentrate shipped from the deposit would head to Asian markets for smelting and refining.³ In a November 2017 presentation to investors, NDM CEO Ron Thiessen said, “You can’t find a better spot to build and develop a mine. It’s effectively in the middle of nowhere, but it’s very close to tidewater, which gives us good access to the ocean and shipment to Asian smelters.”

That plan has not changed. In the Final Environmental Impact Statement developed by the U.S. Army Corps of Engineers, a map in Appendix H clearly illustrates the vessel routes “to Asia ports.”⁴

Shipping concentrate to other countries isn’t unusual for mines in Alaska, which produce 36% of the state’s exports.^{5 6 7}

Pebble developers envision a port on Cook Inlet that would provide easy access to those markets. If the U.S. wanted that Alaska-sourced copper, gold, molybdenum or rhenium in the future, it would have to buy the refined product back from another country, likely China or Japan, which have the smelting and refining capacity that the U.S. currently lacks.

Alaska Senator Lisa Murkowksi and other legislators⁸ have been pointing out the flaws in this supply chain for years.⁹

Not controlling the production aspect of the mineral supply chain leaves the nation at the mercy of countries who may or may not choose to sell refined metals, critical minerals and rare earths to the U.S. in the future.

In the 2019 USGS Critical Minerals Review, authors note, “It is not always the case that the strategic vulnerability for a given mineral commodity is a mining and concentrate production issue…Simply establishing domestic mining and concentrate production does nothing to mitigate risks if downstream processing is highly concentrated geographically, imported and unreliable.”¹⁰

In a 2019 interview with SmithWeekly, NDM’s CEO Ron Thiessen discussed this lack of U.S. processing capacity as well, noting that the last time a copper smelter was permitted in the United States was in 1974. He noted it was never built.¹¹

Yet the company’s August 2020 presentation to investors still highlights Pebble as a “key domestic source of strategic minerals.”¹²

This argument continues to resonate with some supporters of the project. Public comments¹³ on the Final Environmental Impact Statement show concern over resource independence as a reason for developing the Pebble deposit:

• “I believe this project is imperative to the future of the United States due to the coming supply issue for critical minerals…This project will also help the United States become more dependent on our own natural resources for rare Earth’s minerals such as Rhenium and Molybdenum instead of relying on places like China.”
• “I think this project should go forward I am afraid of the Chinese and their dominance of critical minerals needed to defend our country.”
• “I am concerned about our reliance on china for scarce resources. Roughly 5 years ago China weaponized rare earth metals against Japan. They could do the same thing to the untied states… We need this mine to ensure our safety. We can not allow this metals and minerals to be weaponized against us.”

The irony of this argument is that, once developed, Pebble might be sending minerals from the U.S. directly to China. Or Japan, South Korea, or Chile. Any place with capacity to process the concentrate. At that point, it is out of U.S. hands.

In early September 2020, Axios¹⁴ wrote about the global need for copper, and quoted Pebble Limited Partnership spokesperson Mike Heatwole: “While we can’t say for certain where Pebble copper will end up, U.S. and global demand for clean and renewable power, electrical vehicles and the grid infrastructure that supports these … will clearly be important drivers for the development of new copper producers.”

But Pebble is in the U.S., so it’s a domestic supply, right?

The United States Geological Survey keeps track of mineral supplies¹⁵, and copper concentrates don’t count toward domestic supply numbers unless they are smelted and refined domestically.

When determining the amount of domestic supply of refined copper in the U.S., any concentrates shipped and refined overseas don’t factor in. In calculating the supply of domestically mined copper, concentrates extracted here would be considered, but any amount shipped overseas will be subtracted out in the calculation, and only those concentrates that remain in the country will be accounted for as being supplied domestically.

For copper producers like Pebble that aren’t in the smelting/refining business, there can be tolling agreements where Company A produces concentrates, Company B smelts/refines the concentrates and returns them to Company A. Then Company A is in charge of the sale and distribution of the refined copper cathodes. In a scenario where there’s a toll agreement to process concentrates into cathode, the resulting refined production would count as domestic supply. That scenario has never been described as part of Pebble’s plan.

Unless Pebble developers change plans to seek out toll agreements or direct concentrate to facilities in the U.S., Alaska-sourced copper will not count toward the nation’s domestic supply.

Could Pebble send concentrate to U.S. smelters, thus keeping these minerals for domestic supply?

It would be very unlikely, and expensive.

There is no economic benefit for Pebble to do so, even if it could find capacity.

Multiple U.S. copper producers state in their financial reports that 100% of their copper concentrates are sold to foreign companies.¹⁶ The few U.S.-based smelters and refineries in existence are already associated with or owned by large mining companies such as Freeport, Asarco, and Rio Tinto. (Even they send some of their own concentrate to Asia through a port in Guaymas, Mexico.)^{17 18 19}

Those companies would have to agree to take on Pebble concentrates for processing, when they already have limited capacity for their own concentrate.

Additional costs would be incurred to ship Pebble concentrate from Cook Inlet to a port in the U.S. and then by truck or train to smelters in Utah or Arizona and refineries in Texas.²⁰ Shipping from Alaska to another U.S. port is considerably more expensive than shipping to Asia markets due to the Jones Act, which requires goods shipped between U.S. ports to be transported on ships that are built, owned, and operated by United States citizens or permanent residents.²¹

There are even fewer options in the U.S. for rhenium production. Rhenium is produced as a by-product of molybdenum. The USGS Critical Minerals report on rhenium states that in 2012, there were three molybdenum mines in the U.S. with associated roasters. Only one of the roasters – Sierrita in Arizona – was equipped to recover rhenium.²² A 2018 USGS dataset reports that, “the United States has insufficient processing capacity to meet domestic need for rhenium. The United States ships molybdenum concentrates to Chile for recovery and then imports the refined rhenium.”²³

Finally, NDM is an exploration company, not a mining company. Its main goal is to bring on partners to develop the mine, or to sell outright, for the ultimate benefit of its investors. Would future partners put a high value on U.S. resource independence as part of their calculus when determining the economics of Pebble? Would they seek out toll agreements or costly and convoluted shipping modes just to keep concentrate within the U.S.?

Statistics for Pebble’s contribution to resource independence are misleading

Even if Pebble concentrate were by some chance to remain in the domestic supply chain, Pebble exaggerates its contribution to resource independence by citing estimates from the full Pebble deposit.

• Pebble website: “The 80 billion pounds of copper estimated in the Pebble deposit has the potential to meet approximately 33% of U.S. annual needs for many years.”²⁴

• NDM press release on rhenium: “New Pebble mineral resource estimate increases US strategic Rhenium sources by 84%”²⁵

But the project under consideration would produce a fraction of that amount. An expansion of the mine plan beyond that would require additional permitting.

Under the 20-year plan, NDM proposes to mine 318 million pounds of copper annually. Over 20 years, this is 6.3 billion pounds recovered out of an estimated 83 billion pounds (approximately 7.7% ).²⁶

NDM has not provided a breakdown of how much rhenium would be recovered under its existing 20-year plan. The NDM technical report on rhenium is expected to be made public within 45 days of its August 20 press release (early October) and may include this information.

However, since rhenium is produced as a by-product of molybdenum smelting, we can get a general idea of how much rhenium could be produced based on the percentage of molybdenum recovered under the 20-year plan. Under that plan, NDM estimates an average molybdenum concentration production of 14 million pounds. Over 20 years, this is 280 million pounds recovered out of an estimated 5.6 billion pounds (approximately 5%).

	Overall estimate in all categories	Estimated amount to produce under existing 20 year mine plan proposal	Percentage of overall resource to be produced in 20 years
Copper	83 billion lb	6.3 billion lb	7.7%
Molybdenum	5.6 billion lb	280 million lb	5%
Rhenium	4.2 million kg	Not published	Not available, but likely similar to percentage for molybdenum, as rhenium is produced as a by-product of molybdenum

Questions

The promise of the Pebble deposit is exciting for many. There would be jobs and economic benefits. There would be more copper, gold, molybdenum, silver and rhenium extracted from Alaska bedrock. But if Pebble developers continue to claim these minerals as a domestic source of strategic minerals, more details are needed that describe exactly how those minerals will be mined, smelted, refined and retained within the U.S. for its benefit.

---
